| 1 |
CEM discover Microwave synthesizer (RV) |
Microwave assisted wet chemical synthesis |
precursor,solvent and surfactant if any |
| 2 |
Indfur made tubular furnace (1000O) (RV) |
|
|
| 3 |
Nebertherm made box furnace (1400O) (RV) |
|
|
| 4 |
Nebertherm made three zone furnace (RV) |
|
|
| 5 |
Indfur made box furnace (1000O) (RV) |
|
|
| 6 |
SEM/EDAX (Normal)RV-VA |
Resolution : 3.5 nm Images : secondary electron image, backscattered electron images (composition, topography, shadow) Magnification : x18 to 300,000 (in 136 steps) Accelerating Voltage : 0.5 to 30 kV (53 steps) Specimen temp. : LN2 to 200 C |
bulk, powder thin films |
| 7 |
Veco make SPM scanning probe microscope (RV) |
Atomic force microscope with different modes and with MFM |
Thin films,polymer sheets and polished pellets with typical size < 5mmX5mm with polished surface |
| 8 |
Bruker made Bio-AFM (Bioscope resolve) (RV) |
Bio-AFM with different modes at room temperature |
Thin films,polymer sheets and polished pellets with typical size < 5mmX5mm with polished surface |
| 9 |
Nanoscope E AFM from DI, USA (RV) |
|
|
| 10 |
Quantum design make Physical property measurement system (PPMS) (RV) |
Physical property measurement system for Resistivity and heat capacity measurement 14T/2K |
Pellets and thinfilms |
| 11 |
FE-SEM - FEI made NOVA NANOSEM 450 (RV) |
FEI made FESEM with Bruker made EDS and Raith Eline nanolithography attachements |
Powder or thinfilms (non magnetic, dry and preferably electrically conducting at room temperature |
